Hanna Edge® EC/TDS/Salinity Multiparameter (HI2030)

edge’s groundbreaking design is the culmination of Hanna’s vision, design capabilities, integrated production and world class R&D. The edge meter is only 0.5” thick yet rich in features to accommodate the needs of a vast amount of customers. For those that prefer very simplistic operation there is a basic mode operation with simplified menu and options while for those who require advanced features there is the full featured standard operating mode. The edge HI2030 EC/TDS/Salinity kit can can be upgraded at any time with additional probes to measure pH or Dissolved Oxygen.

FEATURES OF EDGE® EC/TDS/SALINITY MULTIPARAMETER (HI2030)

• pH Range -2.00 to 16.00 pH, -2.000 to 16.000 pH*.
• pH Resolution 0.01 pH, 0.001 pH*
• pH Accuracy ±0.01pH, ±0.002 pH*.
• EC Accuracy ±1% of reading (±0.05 μS/cm or 1 digit, whichever is greater).
• EC Calibration 1 Cell Factor calibration; 6 standards available.
• TDS Resolution 0.01 ppm, 0.1 ppm, 1 ppm, 0.01 g/L, 0.1 g/L.
• TDS Accuracy ±1% of reading (±0.03 ppm or 1 digit, whichever is greater).
• TDS Calibration tdrough EC calibration.
• EC to TDS Conversion Factor 0.40 to 0.80 (default value is 0.50).
• Salinity (% NaCl) Range 0.0 to 400.0% NaCl *.
• Salinity (% NaCl) Resolution 0.1% NaCl.
• Salinity (% NaCl) Accuracy ±1% of reading.
• Salinity (% NaCl) Calibration Single point witd HI 7037L Standard.
• Salinity (PSU) Range 2.00 to 42.00 PSU *.
• Salinity (PSU) Resolution 0.01 PSU,.
• Salinity (PSU) Accuracy ±1% of reading.
• Salinity Range 0.0 to 80.0 g/L *.
• Salinity Resolution (ppt) 0.01 g/L.
• Salinity Accuracy (ppt) ±1% of reading.
• Dissolved Oxygen Measurement Type polarographic.
• Dissolved Oxygen Range 0.00 to 45.00 ppm (mg/L), 0.0 to 300.0%.
• Dissolved Oxygen Resolution 0.01 ppm (mg/L), 0.1%.
• Dissolved Oxygen Accuracy ±1.5% of reading.
• Salinity Compensation 0 to 40 g/L 1 g/L.
• Altitude Compensation -500 to 4,000 m (-1640 to 13120’) 100 m (328’).
• Temperature Range -20.0 to 120.0 ºC, -4.0 to 248.0 °F.
• Temperature Resolution 0.1 °C, 0.1 °F.
• Temperature Accuracy ±0.5 °C, ±1.0 °F.
• EC/TDS Probe HI 763100 EC/temperature probe.
• Connectivity 1 micro USB port for charging and PC connectivity, 1 USB port for storage.
• Battery Type/Life Built-in rechargeable battery witd up to 8 hours of continuous use.
• Power Supply 5 VDC adapter (included).
• Environment 0 to 50°C (32 to 122°F), RH max 95% non-condensing.
• Dimensions 202 x 140 x 12.7mm (8” x 5.5” x 0.5”).
• Weight 250 g (8.82 oz).
• Ordering Information HI2030 EC kit includes.
• Notes temperature limits will be reduced to actual probe/sensor limits.

SPECIFICATION OF EDGE® EC/TDS/SALINITY MULTIPARAMETER (HI2030)
