120Z-12 Starrett Dial Caliper with White Face in Fitted Plastic Case 0-12*

120Z-12

The Only American Made Dial Caliper …
This is one of the handiest measuring tools available, used by mechanics and
toolmakers everywhere. It is direct reading, reliable and accurate.

Readability Features

• Sharp, clear dial graduations of .001″ or 0.02mm – .100″ or
  2mm in one revolution
• Sharp, black graduations on the satin finished bar, every .100″
  or 1mm
• Choice of black, red, or white inch dials; millimeter dials are yellow

Ease-of-Handling Features

• Knife-edge contacts for both inside and outside measurements
• One hand use with the thumb-operated, fine adjustment roll
• Lock screw for dial bezel and for holding the sliding jaw in position
• 6″ (150mm) and 9″ (225mm) models have a covered rack depth rod.
  Detachable depth rod available for 12″ (300mm) model
• Parallel lines can be scribed on a workpiece by setting the caliper
  jaw to the required dimensions, locking the movable jaw with the
  lock screw and then using the front edge of the fixed jaw as the
  scribing surface

Accuracy and Long-Life Features

• Long-wearing carbide faces on outside contacts on model 120AX-6 and 120MX-150
  only
• Hardened stainless steel bar, measuring surfaces, rack, gears and depth
  rod
• Positive, split-gear anti-backlash control
• Rack teeth point down to make it easy to shed foreign matter and
