14 Megger Bite2 and Bite2p Battery Impedance Tester

The BITE2 and BITE2P battery impedance test equipment determine the condition of lead-acid and nickel-cadmium cells up to 7000 Ah. An advanced feature set has been developed that includes Pass/Warning/Fail calculations based on a user-entered baseline value, advanced printing functions and more. The case of the BITE2P consists of both the transmitter and a carrying case for all of the standard accessories and some of the optional accessories, in an all-in-one unit. The BITE2 and its accessories fit into a sturdy canvas case with a shoulder strap.

The instruments work by applying a test current across the battery string while on-line, then measuring the total current (ac ripple + test current) and the voltage drop of each cell/jar. It then calculates the impedance. They also measure dc voltage and interconnection (strap) resistance to help determine the overall condition of the entire battery string’s electrical path from the terminal plate to the terminal plate.

Key Features: Megger EZ THUMP V2 12 kV HIGHLY PORTABLE FAULT LOCATION SYSTEM

• Compact, light and rugged field instruments
• Battery and AC line operation
• Automatic end-of-cable and fault locating
• 4-kV or 12-kV output versions available
• Transflective colour display
• ARM® Prelocation
• Fault Pinpointing (Thumping)
• Optional Sectionalising Software*
