Emergency Eye/Face Wash Fountain with Pedal SS CHINA
৳ 14,500.00
STANDARD: IS 10592:2018, ANSI Z358.1
- Water inlet connections of 1-¼” NB
- Water outlet connection – 1¼” NB
- Head shower discharge rate – 76 lpm (minimum)
- Eye wash discharge rate – 12 lpm. (minimum)
- Powder coated materials for better protection and durability.
- Push to open valve – connects unit to uninterruptible water supply.
- Push plate for one hand operation.
- Base plate – to hold the shower structure in a stable position (Size-180 mm).
- Newly introduced straight model body for better flow of water in minimum time.
- With foot pedal for hands free operation to supply and control water flow through eye wash heads
Eye Wash Station is a Foot Pedal Eye Wash station. it is used to remove chemicals from eyes. this eye wash station can remove chemicals quickly Through water that you can simply operate. it is a portable eye wash station. You can easily move from one place to another place. This eye wash station can be operated by foot. If you want to set up the best eye wash station, Eye Wash Station can be the best eye wash station. it will wash your eyes and facial area together. The importance of eye wash stations is not limited. Eye Wash Station provides emergency first aid when someone’s eyes come in contact with hazardous chemicals and corrosive substances.
FEATURES OF Emergency Eye/Face Wash Fountain with Pedal SS
- Easy to operate.
- Recommended water pressure 30 PSI.
- Light weight (9kg) and durable device.
- Alkalis, salt, oils, acid Damage Resistant.
- High Visibility Yellow and Green Color.
EYE / FACE WASH FOUNTAIN
Eye wash fountain head is between 830-1140 mm (83 cm-114
cm) above floor surface
EYE WASH HEAD
Two high-flow sprays, operated at low pressure, which washes
the eye and face.
Anti-dust cover protects the head from airborne contaminants
and automatically opens with water pressure.
Distance between two eye wash head is 140 to 200 mm as per
standard
PUSH TO OPEN VALVE
½” BSP Ball valve connects units to uninterruptible water
supply as per requirements
Udyogi 294, B. B. Ganguly Street,
2nd Floor, Kolkata – 700 012
Scan Here for More Info
EASY OPERATION FIRST AID AIDING EQUIPMENT SUPPLY WATER CONDITION
Supply Water
Operating
Pressure
Drinking /
Tepid Water
2.1 Kg / cm2
(30 PSI)
MATERIAL
Pipe GI with powder coated Fitting
Operating Temp
Ambient
Flange
SHOWER HEAD & VALVE FUNCTIONS
Provided S.S 304 valve that opens automatically when Pull Rod
is pulled.
The valve stays open until it is manually closed.
Shower head is between 2100 mm – 2400 mm above floor
surface as per standards.
Shower bowl dia 270 ± 5 mm
Pull rod height is 1752 mm max from ground as per standards.
1” lock nut provided for perpendicular positioning of the bend
pipe and shower bowl
SPECIFICATION OF Emergency Eye/Face Wash Fountain with Pedal SS
| Name | Details |
|---|---|
| Model | SS |
| Brand | Merkode |
| Origin | China |
| Water inlet connections of
Eye wash discharge rate |
1/2’’ NB for eye / face wash.
12 lpm. (minimum) |
| Weight | ±17.80 kg |
| Water outlet connection | 1¼” NB |
| Supply | 30 PSI |
| Recommended Pressure | 30 PSI-2.1 kg |
| Standard: IS: | IS 10592:2018, ANSI Z358.1 |
