Kyoritsu Kew 1021R Digital Multimeter
৳ 8.00
Safety Designed Multimeter
- Accurate reading with True RMS
- Large display with 6000 counts and Backlight
- MIN/MAX function
- Rugged and reliable
- Enhanced current measuring function using an external clamp sensor
- Sensor mode (with clamp sensor)
- Ergonomic design
- Safety Standard IEC 61010-1 CAT Ⅳ 300V / CAT Ⅲ 600V
Description
Kyoritsu KEW 1021R Digital Multimeter
The Kyoritsu KEW 1021R is a professional True RMS digital multimeter designed for electrical and industrial measurement work. It features a 6000-count backlit display, auto-ranging, MIN/MAX function, and safety ratings up to CAT IV 300V / CAT III 600V.
Key Specifications
| Feature | Specification |
|---|---|
| DC Voltage | 600 mV / 6 / 60 / 600 V |
| AC Voltage | 600 mV / 6 / 60 / 600 V |
| DC Current | 6 A / 10 A |
| AC Current | 6 A / 10 A |
| Resistance | Up to 40 MΩ |
| Capacitance | Up to 1000 µF |
| Frequency | Up to 99.99 kHz |
| Diode Test | Yes |
| Continuity Buzzer | Yes |
| Display | 6000 counts, backlight |
| True RMS | Yes |
| Safety Standard | IEC 61010-1 CAT IV 300V / CAT III 600V |
| Power | 2 × 1.5V R03 batteries |
| Weight | Approx. 250 g |
Specifications are from Kyoritsu’s official product documentation.
Main Features
- True RMS measurement
- Auto-ranging
- Large backlit LCD
- MIN/MAX measurement
- AC/DC voltage and current measurement
- Resistance, capacitance and frequency measurement
- Diode and continuity testing
- Optional AC/DC clamp sensor support
- Compact ergonomic design.
Specification
| DC V | 6.000/60.00/600.0V (Auto-ranging) ±0.5%rdg ±3dgt |
|---|---|
| DC mV | 600.0mV ±1.5%rdg ±3dgt |
| DC Clamp Sensor | 60.00/200.0A (Auto-ranging) ±1.5%rdg ±3dgt + Sensor accuracy |
| AC V | 6.000/60.00/600.0V (Auto-ranging) ±1.0%rdg ±3dgt [40 to 500Hz] |
| AC mV | 600.0mV ±2.0%rdg ±3dgt [40 to 500Hz] |
| AC Clamp Sensor | 60.00/200.0A (Auto-ranging) ±2.0%rdg ±3dgt + Sensor accuracy [40 to 500Hz] |
| DC A | 6.000/10.00A (Auto-ranging) ±1.5%rdg ±3dgt |
| AC A | 6.000/10.00A (Auto-ranging) ±1.5%rdg ±3dgt[45 to 500Hz] |
| Ω | 600.0Ω/6.000/60.00/600.0kΩ/6.000/40.00MΩ (Auto-ranging) ±0.5%rdg ±4dgt (600Ω) ±0.5%rdg ±2dgt (6/60/600kΩ/6MΩ) ±1.5%rdg ±3dgt (40MΩ) |
| Continuity buzzer | 600Ω (Buzzer sounds below 90Ω) |
| Diode test | Open circuit voltage: < 3.0V |
| Capacitance | 60.00/600.0nF/6.000/60.00/600.0/1000µF ±2.0%rdg ±5dgt (60/600nF) ±5.0%rdg ±5dgt (6/60/600/1000µF) |
| Frequency | ACV 99.99/999.9Hz/9.999/99.99kHz ±0.1%rdg ±3dgt ACA 99.99/999.9Hz/9.999kHz ±0.1%rdg ±3dgt |
| DUTY | 10.0 to 90.0% ±1.0%rdg ±3dgt [50/60Hz] |
| Applicable standards | IEC 61010-1 CAT IV 300V / CAT III 600V IEC 61010-2-033, IEC 61010-031, IEC 61326-2-2 (EMC), EN 50581 (RoHS) |
| Power source | R03 (1.5V) × 2 |
| Dimension | 155(L) × 75(W) × 40(D)mm |
| Weight | Approx. 250g (including batteries) |
| Accessories | Wing-type holder Flat-type holder 7066A (Test leads) 8919 (Ceramic fuse [10A/600V]) × 1 (included) 9097 (Carrying case) R03 × 2 Instruction manual |
| Optional accessories | 7234 (Alligator clip) 8161 (AC clamp adaptor) 8115 (AC/DC clamp sensor) 9189 (Magnet hanger strap) |
